Description
The newly designed MRCOOL 4th generation Advantage Series 9,000 BTU ductless mini split air conditioner has improved efficiency ratings up to 21.5 SEER and is competitively priced. It provides maximum comfort and is designed to heat and cool 375 square feet without requiring any ductwork. This system also comes with a 16 ft. install kit that includes a 100% copper line set. Both the wall mounted air handler and the condenser operate quietly for your comfort while also being eco-friendly, with chlorine-free R-410A refrigerant. This unit is 115V, but we also carry the 230V MRCOOL Advantage 9,000 BTU.
- 16 ft. install kit included. Contains 16ft line set, copper tubing
- 10,000 BTU Heat Pump
- Temperature range: 61°F – 86°
- R-410A environmentally friendly refrigerant
- Sleep mode, louver position memory, gold fin anti-corrosion and auto restart functions
- 1-year compressor, 2-year parts warranty when registered and when installed by a licensed professional
- Installation by a licensed professional required
- Includes Remote
Looking for a Do-It-Yourself unit? DIY 9,000 BTU Mini Splits
| BRAND NAME | MRCOOL |
| SERIES |
Advantage Series 4th Gen
|
| MODEL | A-09-HP-115C |
| GTIN | 840255521819 |
| UPC | 840255521819 |
| UNIT TYPE | Mini-Split |
| SHORT DESCRIPTION |
This new 4th generation Advantage series has an improved SEER rating of 21.5.
|
| LONG DESCRIPTION |
Designed to be installed by an HVAC technician, this newly designed 4th generation Advantage Series has a newly improved efficiency rating of 20.5. From the moment of installation and activation, this system provides high performance at a competitive price. In order to remain eco-friendly, the condenser uses chlorine-free R-410A refrigerant. This is a great choice for those looking for quality, value, efficiency, and quiet operation. If you’re looking for superior performance and technology, look no further than this system’s WiFi control module. It allows for an easier setup process and improved functionality, as well as allowing control via your Amazon Alexa or Google Assistant.
|
| BULLET 1 |
Installation kit included
|
| BULLET 2 |
Gold Fin® condenser: corrosion resistant - live on the coast? Don't worry, our condenser is built to resist long term corrosion
|
| BULLET 3 |
The new 4th generation Advantage systems include our SmartHVAC WiFi Control Module with improved setup and enhanced functionality for Apple and Android smart devices. Works with Amazon Alexa. Works with Google Assistant.
|
| BULLET 4 |
Installation by a licensed professional required where applicable
|
| BULLET 5 |
1-Year Compressor, 2-Year Parts and 1-Year Remote Warranty when registered and when installed by a licensed professional
|
| BULLET 6 |
R-410A environmentally friendly refrigerant
|
| BULLET 7 |
Sleep mode, louver position memory, and auto restart functions
|
| BULLET 8 |
Convenient for installation and maintenance, compact design of outdoor unit, totally enclosed, permanently lubricated condenser fan motor
|
| SEER | 20.5 |
| SEER2 | 21.5 |
| EER | 12.5 |
| EER2 | 12.5 |
| HSPF |
hspf4/hspf5: 10/7.8
|
| HSPF2 |
hspf2-4/hspf2-5: 9/6.9
|
| COOLING CAPACITY | 9000 |
| HEATING CAPACITY | 10000 |
| VOLTAGE | 115V |
| PHASE | 1 |
| CYCLE | 60Hz |
| MAX FUSE BREAKER | 30 A |
| MIN CIRCUIT AMPACITY | 20 A |
| COLOR | White |
| MAX COVERAGE AREA | 375 sqft |
| ZONE CAPACITY | 1 |
| REFRIGERANT TYPE | R-410A |
| REFRIGERANT VOLUME | 25.40oz |
| DECIBEL RATING | 31 dBA |
| DECIBEL RATING LOW | 22 dBA |
| DECIBEL RATING HIGH | 36.5 dBA |
| NUMBER OF SPEEDS | 3 |
| MIN AMBIENT HEAT | 5 Degrees F |
| LIQUID LINE SIZE | 1/4 in |
| SUCTION LINE SIZE | 3/8 in |
| FILTER TYPE | Washable |
| LOW VOLTAGE COMPENSATION | No |
| OVERLOAD PROTECTION | Yes |
| ADJUSTABLE THERMOSTAT | Yes |
| FAN ONLY OPTION | Yes |
| QUIET MODE | Yes |
| SLEEP MODE | No |
| AUTO COOL | Yes |
| WIFI COMPATIBILITY | Yes |
| APP COMPATIBILITY | Yes |
| WORKS WITH IOS | Yes |
| WORKS WITH ANDROID | Yes |
| REMOTE CONTROL INCLUDED | Yes |
| UL LISTED | Yes |
| CSA LISTED | Yes |
| ETL LISTED | Yes |
| ENERGY STAR COMPLIANT | No |
| ENERGY STAR CERTIFIED | No |
| AHRI CERTIFIED | Yes |
| REGISTERED WARRANTY |
1-Year Compressor, 2-Year Parts and 1-Year Remote
|
| BASE WARRANTY | None |
| REGISTERED PARTS WARRANTY | 2-year |
| BASE PARTS WARRANTY | None |
| REGISTERED COMPRESSOR WARRANTY | 1-year |
| BASE COMPRESSOR WARRANTY | None |
| REGISTERED REMOTE WARRANTY | 1-year |
| BASE REMOTE WARRANTY | None |
| REGISTERED LABOR WARRANTY | None |
| BASE LABOR WARRANTY | None |
| HAS BATTERIES | Yes |
| CONTAINS ELECTRONICS | Yes |
| CONTAINS CHEMICALS | Yes |
| CONTAINS AEROSOL | Yes |
| CONTAINS COMPRESSED GAS | Yes |
| PROPOSITION 65 WARNING | Yes |
| CONDENSER DEPTH | 11.93 in |
| CONDENSER HEIGHT | 21.85 in |
| CONDENSER WIDTH | 30.12 in |
| CONDENSER WEIGHT | 57.76 lbs |
| AIR HANDLER DEPTH | 7.36 in |
| AIR HANDLER HEIGHT | 11.42 in |
| AIR HANDLER WIDTH | 28.43 in |
| AIR HANDLER WEIGHT | 16.98 lbs |
