Product overview
MRCOOL DIY Easy Pro 24,000 BTU 18.9 SEER2 Ductless Mini Split Air Conditioner and Heat Pump - 230V
The MRCOOL Easy Pro® DIY 24K BTU Ductless Mini-Split Heat Pump System is easy to install and is capable of effectively heating and cooling a space of 1,050 square feet, this easy-to-install unit also includes the convenient 11.5 foot pre-charged line set, with Fast Connection® fittings.
The features are numerous with this system such as the Follow Me® feature can make sure that the temperature you want is designated to wherever you are in the space, as well as the anti-mildew feature that provides the cleanest air for you and your family to breathe. Maintaining the system is as easy as the installation, as the air filters only require rinsing and replacing, and the LED display provides useful troubleshooting codes for you to solve any issue that arises on your own.
This system can be operated with your Apple or Android device via the SmartHVAC app, the included remote control, or your Amazon Alexa or Google Assistant. Feel confident in your purchase with the 5-year compressor warranty and 3-year parts warranty. This is an easy-to-install system that can provide exceptional heating and cooling for your home or office.
Key Features:
- Smart Control
- DIY Installation
- Energy Efficient
- Quiet Operation
- Durable Design
What It Includes:
- Indoor Units (MRCOOL® DIY Easy Pro® 24k BTU Ductless Mini-Split Heat Pump Air Handler)
- Outdoor Unit (MRCOOL® DIY Easy Pro® 24k BTU Ductless Mini-Split Heat Pump Condenser)
- 11.5 Ft Pre-Charged Installation Kit Included
- Wireless Remote Controls
- Installation Manual
- User’s Manual
- Manufacturer Warranty
Condenser Specs:
| BRAND NAME | MRCOOL |
| SERIES | DIY EasyPro |
| MODEL | EZPRO-24-HP-C-23011DE-O |
| GTIN | 840255595995 |
| UPC | 840255595995 |
| SHORT DESCRIPTION |
DIY Easy Pro® - R454B DIY 24K BTU Ductless Mini-Split Heat Pump Condenser, 230V, with 11.5 ft Install Kit
|
| SEER2 | 18.9 |
| EER2 | 9.7 |
| HSPF2-4 | 8.7 |
| HSPF2-5 | 6.9 |
| TONNAGE | 2 |
| COOLING CAPACITY (BTU) | 24000 |
| HEATING CAPACITY (BTU) | 25000 |
| VOLTAGE (V) | 208/230 |
| PHASE | 1 |
| CYCLE | 60 |
| MAX FUSE BREAKER (A) | 20 |
| MIN CIRCUIT AMPACITY (A) | 19 |
| COLOR | White |
| ZONE CAPACITY | 1 |
| REFRIGERANT TYPE | R-454B |
| REFRIGERANT VOLUME (OZ) | 50.44 |
| DECIBEL RATING (DBA) | 61 |
| INVERTER | Yes |
| LINESET INCLUDED | Yes |
| LINE SET LENGTH | 11.5 ft. |
| MAX LINESET LENGTH (FT) | 75 ft. |
| LIQUID LINE SIZE | 3/8 |
| SUCTION LINE SIZE | 5/8 |
| COMPRESSOR MOTOR TYPE | Rotary |
| CONDENSER FAN MOTOR TYPE | DC |
| CONDENSER FAN MOTOR RPM | 830/700/550 |
| METERING DEVICE | EEV |
| UL LISTED | Yes |
| CSA LISTED | Yes |
| ETL LISTED | Yes |
| ENERGY STAR CERTIFIED | No |
| AHRI CERTIFIED | Yes |
| BASE WARRANTY | 3 Year Parts, 5 Year Compressor |
| BASE PARTS WARRANTY | 3 Year Parts |
| BASE COMPRESSOR WARRANTY | 5 Year Compressor |
| CONTAINS ELECTRONICS | Yes |
| CONTAINS CHEMICALS | Yes |
| CONTAINS COMPRESSED GAS | Yes |
| PROPOSITION 65 WARNING | Yes |
| NET DEPTH (IN) | 13.46 |
| NET HEIGHT (IN) | 26.5 |
| NET WIDTH (IN) | 35.04 |
| NET WEIGHT (LBS) | 95.9 |
| GROSS DEPTH (IN) | 15.67 |
| GROSS HEIGHT (IN) | 29.13 |
| GROSS WIDTH (IN) | 39.17 |
| GROSS WEIGHT (LBS) | 117.73 |
Air Handler Specs:
| BRAND NAME | MRCOOL |
| SERIES | DIY EasyPro |
| MODEL | EZPRO-24-HP-WMAH-230DE-O |
| GTIN | 840255596015 |
| UPC | 840255596015 |
| SHORT DESCRIPTION |
DIY Easy Pro® - R454B DIY 24K BTU Ductless Mini-Split Heat Pump Wall Mounted Air Handler, 230V, with 13' Communication Cable
|
| CFM | 729.9 / 547.4 / 400.2 / 329.6 |
| TONNAGE | 2 |
| VOLTAGE (V) | 208/230 |
| PHASE | 1 |
| CYCLE | 60 |
| MAX FUSE BREAKER (A) | 15 |
| MIN CIRCUIT AMPACITY (A) | 3 |
| COLOR | White |
| MAX COVERAGE AREA | 1050 sq. ft. |
| ZONE CAPACITY | 1 |
| REFRIGERANT TYPE | R-454B |
| DECIBEL RATING LOW (DBA) | 21.5 |
| DECIBEL RATING HIGH (DBA) | 51.5 |
| OSCILLATION | Yes |
| BLOWER MOTOR TYPE | DC |
| BLOWER MOTOR RPM | 1100/940/780 |
| FILTER TYPE | Reusable |
| ADJUSTABLE THERMOSTAT | Yes |
| FAN ONLY OPTION | Yes |
| SLEEP MODE | Yes |
| AUTO COOL | Yes |
| WIFI COMPATIBILITY | Yes |
| APP COMPATIBILITY | Yes |
| WORKS WITH IOS | Yes |
| WORKS WITH ANDROID | Yes |
| REMOTE CONTROL INCLUDED | Yes |
| BASE WARRANTY | 3 Year Parts |
| BASE PARTS WARRANTY | 3 Year Parts |
| BASE REMOTE WARRANTY | 3 Year |
| HAS BATTERIES | Yes |
| CONTAINS ELECTRONICS | Yes |
| CONTAINS CHEMICALS | Yes |
| CONTAINS COMPRESSED GAS | Yes |
| PROPOSITION 65 WARNING | Yes |
| NET DEPTH (IN) | 9.21 |
| NET HEIGHT (IN) | 13.27 |
| NET WIDTH (IN) | 42.6 |
| NET WEIGHT (LBS) | 35.49 |
| GROSS DEPTH (IN) | 17.67 |
| GROSS HEIGHT (IN) | 14.09 |
| GROSS WIDTH (IN) | 46.73 |
| GROSS WEIGHT (LBS) | 49.6 |
In-stock systems ship fast and free with curbside freight delivery, typically arriving in 4–10 days. Please inspect each box at delivery and note any damage on the receipt before signing — it keeps any freight claim quick and simple.
