Product overview
MRCOOL VersaPro 24,000 BTU 2 Ton 18.1 SEER2 Central Ducted Heat Pump System
Introducing the new 2nd Gen MRCOOL VersaPro 24,000 BTU 2 Ton Central Ducted Heat Pump System, a variable speed 24K unit boasting an impressive SEER2 of 18.1 and HSPF4 of 9.7. With a DC inverter, this advanced yet affordable unit guarantees excellent operation and reduced utility costs, making it an exceptional upgrade option. The convenience of installation is further enhanced due to it's compatibility with the MRCOOL® Quick Connect® precharged line set, facilitating swift and trouble-free setup for professional HVAC technicians. The Precharged lineset is sold separately with eco-friendly R-454B refrigerant, which eliminates the need for vacuuming and ensures a seamless connection. This unit features a robust build and finish utilizing painted galvanized steel, ensuring longevity. Additionally, the condenser has a compact, side-discharge design and self-diagnostic capabilities simplify maintenance efforts. Moreover, the 10-year parts and compressor warranty offers added peace of mind and provides hassle-free coverage in the event of unexpected issues.
The MRCOOL VersaPro 24K presents an exceptional and cost-effective option for maintaining year-round comfort in your home efficiently, quietly, and effectively. With its ability to cover an average of 1,000 square feet of space and boasting a SEER2 rating of 18.8, this heating and cooling system serves as a dependable upgrade from older units. Constructed with durable painted galvanized steel, this air handler ensures long-term performance and reliability. Its easily accessible removable filter and self-diagnostics panel simplify maintenance tasks by facilitating quick identification of error codes. Installation versatility is a key feature of the 2 Ton MRCOOL® VersaPro Central Ducted System, allowing for positioning in various configurations such as upflow, downflow, and horizontal orientations. Additionally, an optional heat kit is available for enhanced functionality. Furthermore, the inclusion of a wired thermostat offers convenient and reliable temperature control in any space. Investing in the 2 Ton MRCOOL® VersaPro Central Ducted System comes with the added assurance of a 10-year parts and compressor warranty provided by MRCOOL®, offering comprehensive coverage and enhancing ease of ownership.
Condenser Specifications:
|
BRAND NAME |
MRCOOL |
|
SERIES |
VersaPro® Central Ducted Condenser |
|
MODEL |
MVP-24-HP-C-230A00-O |
|
GTIN |
00840255582698 |
|
UPC |
840255582698 |
|
UNIT TYPE |
Split System Heat Pump |
|
EQUIPMENT TYPE |
Condenser |
|
SHORT DESCRIPTION |
2 Ton MRCOOL® VersaPro® Central Ducted Heat Pump Condenser |
|
LONG DESCRIPTION |
Enhance your home’s comfort with the 2 Ton MRCOOL® VersaPro® Central Ducted Heat Pump Condenser, designed for both efficiency and reliability. This system is built to meet your heating and cooling needs while helping to keep energy costs low. With a 24K BTU capacity, the VersaPro® features a variable-speed design that delivers an impressive SEER2 rating of 18.1 and an HSPF4 rating of 9.7. When paired with the MRCOOL® VersaPro® Central Ducted Air Handler, you create a tailored system for your home’s specific needs. The advanced DC inverter technology ensures consistent performance, adjusting to changing temperatures to maintain the ideal indoor environment. It also comes with a MRCOOL® Smart thermostat, making it easy to adjust the temperature to your liking. The VersaPro® condenser uses R-454B refrigerant, which is not only efficient but also eco-friendly. Its durable painted galvanized steel construction promises long-lasting reliability, while the compact side-discharge design and self-diagnostic capabilities make maintenance easier and less time-consuming. With a 10-year warranty on the compressor and parts, you can feel confident that you’re making a smart investment. Make the switch to the 2 Ton MRCOOL® VersaPro® Central Ducted Heat Pump Condenser today and experience unparalleled comfort and energy efficiency in your home for many years ahead. |
|
SEER2 |
18.1 |
|
EER2 |
11 |
|
HSPF-4 |
9.7 |
|
HSPF-5 |
7.7 |
|
CFM |
1765.7 |
|
TONNAGE |
2 |
|
COOLING CAPACITY (BTU) |
24000 |
|
HEATING CAPACITY (BTU) |
26000 |
|
VOLTAGE (V) |
208-230 |
|
PHASE |
1 |
|
CYCLE |
60 |
|
MAX FUSE BREAKER (A) |
20 |
|
MIN CIRCUIT AMPACITY (A) |
19 |
|
COLOR |
Gray |
|
REFRIGERANT TYPE |
R454B |
|
REFRIGERANT VOLUME (OZ) |
74.08 |
|
DECIBEL RATING (DBA) |
60 |
|
LIQUID LINE SIZE |
3/8 |
|
SUCTION LINE SIZE |
3/4 |
|
WIFI COMPATIBILITY |
Yes |
|
APP COMPATIBILITY |
Yes |
|
ETL CERTIFIED |
Yes |
|
ENERGY STAR CERTIFIED |
Yes |
|
AHRI CERTIFIED |
Yes |
|
BASE PARTS WARRANTY |
10 Years |
|
BASE COMPRESSOR WARRANTY |
10 Years |
|
CONTAINS ELECTRONICS |
Yes |
|
CONTAINS CHEMICALS |
Yes |
|
CONTAINS COMPRESSED GAS |
Yes |
|
NET DEPTH (IN) |
13.46 |
|
NET HEIGHT (IN) |
26.5 |
|
NET WIDTH (IN) |
35.04 |
|
NET WEIGHT (LBS) |
102 |
|
GROSS DEPTH (IN) |
15.67 |
|
GROSS HEIGHT (IN) |
29.13 |
|
GROSS WIDTH (IN) |
39.17 |
|
GROSS WEIGHT (LBS) |
109 |
Air Handler Specifications:
|
BRAND NAME |
MRCOOL |
|
SERIES |
VersaPro® Central Ducted Air Handler |
|
MODEL |
MVP-24-HP-MUAH-230A00-O |
|
GTIN |
00840255586450 |
|
UPC |
840255586450 |
|
UNIT TYPE |
Split System Heat Pump |
|
EQUIPMENT TYPE |
Air Handler |
|
SHORT DESCRIPTION |
2 Ton MRCOOL® VersaPro® Central Ducted Air Handler |
|
LONG DESCRIPTION |
The 2 Ton MRCOOL® VersaPro® Central Ducted Air Handler is a reliable and efficient option for year-round heating and cooling your home. With a SEER2 rating of up to 18.3, it’s suitable for spaces up to 1,000 square feet, making it a practical choice for replacing older HVAC systems. Built with durability in mind, the air handler features a painted galvanized steel exterior, ensuring long-lasting performance. The self-diagnostics panel makes maintenance easier, helping identify error codes quickly and simplifying troubleshooting. The unit offers flexible installation options, including upflow, downflow, and horizontal left or right configurations to fit various home layouts. It also uses R-454B refrigerant, an eco-friendly option that reduces environmental impact while maintaining performance. Plus, this air handler works seamlessly with our Central Ducted Hyper Heat system for reliable whole-home comfort. If you need additional heating, an optional heat kit can be added. Combined with the MRCOOL® Smart thermostat, which ensures reliable and easy temperature control, maintaining your home’s ideal comfort level has never been simpler. With a 10-year warranty, the 2 Ton MRCOOL® VersaPro® Central Ducted Air Handler offers dependable performance, energy efficiency, and flexibility, making it an innovative and cost-effective upgrade for your home’s HVAC system. |
|
CFM |
824.04/759.29/694.55/629.80 |
|
TONNAGE |
2 |
|
VOLTAGE (V) |
115/208-230 |
|
PHASE |
1 |
|
CYCLE |
60 |
|
MAX FUSE BREAKER (A) |
15 |
|
MIN CIRCUIT AMPACITY (A) |
5.5/4.0 |
|
COLOR |
Gray |
|
DECIBEL RATING LOW (DBA) |
28 |
|
DECIBEL RATING HIGH (DBA) |
44 |
|
MAX LINESET LENGTH (FT) |
164 ft |
|
LIQUID LINE SIZE |
3/8 |
|
SUCTION LINE SIZE |
3/4 |
|
FILTER TYPE |
Replaceable |
|
FILTER SIZE |
16x20x1 |
|
AUXILIARY HEATER INCLUDED |
No |
|
AUXILIARY HEATER AVAILABLE |
Yes |
|
AUXILIARY HEATER SIZES |
5kW/8kW/10kW/15kW |
|
ADJUSTABLE THERMOSTAT |
Yes |
|
WIFI COMPATIBILITY |
Yes |
|
APP COMPATIBILITY |
Yes |
|
ETL CERTIFIED |
Yes |
|
ENERGY STAR CERTIFIED |
Yes |
|
AHRI CERTIFIED |
Yes |
|
BASE PARTS WARRANTY |
10 Years |
|
BASE COMPRESSOR WARRANTY |
10 Years |
|
CONTAINS ELECTRONICS |
Yes |
|
CONTAINS CHEMICALS |
Yes |
|
CONTAINS COMPRESSED GAS |
Yes |
|
NET DEPTH (IN) |
21.02 |
|
NET HEIGHT (IN) |
45 |
|
NET WIDTH (IN) |
17.52 |
|
NET WEIGHT (LBS) |
105.6 |
|
GROSS DEPTH (IN) |
26.57 |
|
GROSS HEIGHT (IN) |
48.62 |
|
GROSS WIDTH (IN) |
20.87 |
|
GROSS WEIGHT (LBS) |
127.43 |
