TOSOT Aoraki 24,000 BTU 23.5 SEER2 Heat Pump Mini Split AC w/ERV System - 230V
The TOSOT Aoraki Series mini split air conditioner offers energy-efficient cooling and heating with a SEER2 rating up to 23.5. Certified by Energy Star and AHRI, it qualifies for tax credits. Compared to a 16 SEER system, it can lower your energy bills by up to 36%.
The ERV system exchanges stale indoor air with fresh outdoor air, pre-conditioning the incoming air by transferring heat and moisture from the outgoing air to improve indoor air quality and energy efficiency.
Features:
- Exceptional 23-23.5 SEER Rating.
- Energy Star Certified with tax rebate eligibility.
- Compatible with ERV Systems.
- Operates in Extreme Temperatures from -22°F to 122°F
- 5 Year Warranty
- Copper Line Set: 16 Ft
Installation and Guides:
Specifications:
- Cooling Capacity (Btu/h):21,000
- Heating Capacity (Btu/h): 23,000
- EER(Btu/h)/W: 13
- COP(Btu/h)/W: 11
- SEER2: 23.5
- HSPF2: 9.0
- Airflow (H/M/L): 950/670/430 m3/h
- Dehumidification (Pts/hr): 5.07
- Est. Cooling Area (Sq. Ft.): 1500
- Voltage: 187/253~60Hz, 1Ph
- Rated Input(W):3850
- Rated Current(A): 17.2
- Min. Current (MCA) (A) :22
- Max. Rating of Overcurrent Protective(A): 30
- Temperature Range (°F): 61-86
- Noise Level (H/M/L): 48/39/30 decibels
DIMENSIONS & WEIGHTS:
Indoor Unit
- Approximate Shipping Weight (lbs): 35.3
- Approximate Net Weight (lbs): 29.8
- Shipping Dimensions (W×H×D) (inches): 41.57 x 15.17 x 11.74
- Unit Dimensions (W×H×D) (inches): 39.12 x 12.25 x 8.75
Outdoor Unit
- Approximate Shipping Weight (lbs): 114.7
- Approximate Net Weight (lbs): 103.9
- Shipping Dimensions (W×H×D) (inches): 42.55 x 31.91 x 19.03
- Unit Dimensions (W×H×D) (inches): 39.4 x 29.39 x 16.82
Line Set Length
- Copper Line Set(ft): 16
- Copper Line Size: 1/4" & 5/8"
- Signal Cable(ft): 19
- Power Cord(ft):19
